0.35" TFT LCD Module (60 x 60) [ST0035M1W-RSLW-F]

0.35" TFT LCD Module (60 x 60) [ST0035M1W-RSLW-F]

¥0
Sale Sold out
Tax included. Shipping calculated at checkout.

Important Note: Currently,our direct shopping page is designed for orders from Japan. However,we welcome orders from customers outside of Japan. Please submit a direct inquiry using the form "Request Quotation / OtherInquiry" or send an email to s.shop@santekdisplay.com.

Controller Board and LCD Kit are also available for　most of our Santek standard LCD Modules. Please contact us for inquiry.

Contact Now for Shopping




Spec Overview

Size (Inch) 0.35"
Resolutions 60 x 60
Santek Moedl No. ST0035M1W-RSLW-F
Module Size
(W x H x T mm)		 8.22 x 10.25 x 1.06
Active Area
(W x H mm)		 6.41 x 6.41
Interface 4-wire SPI
Brightness    500 cd/㎡
Operating Temperature -20 ~ 70 °C
Viewing Angle Wide (All Direction)



• Santek’s Unique Display Size: 0.35-inch Display
The 0.35-inch display is Santek’s original size. With its compact and refined design, it is ideal for a wide range of applications.

• High Resolution for Clear Visibility
Equipped with a 60×60 dot resolution, it delivers sharp and detailed images.

• Supports SPI Interface
Enables high-speed and efficient data transfer, ensuring smooth operation.

• Wide Viewing Angle
Provides clear visibility from multiple directions, allowing comfortable use from any angle.

• Brightness of 500 cd/m²
Brightness and other specifications can be customized upon request. Please contact us for details—we offer tailored solutions to meet your needs.

• Wide Operating Temperature Range (−20 to 70°C)
Designed to operate reliably even in harsh environments, making it suitable for industrial equipment and outdoor devices.

Log in or Sign in to Download Datasheet

Once you log in, you will return to top page. Select any products to download Spec Sheet. Some spec / data sheets are currently in preparation.
