3.5" TFT LCD Module (320 x 240) Wide Viewing Type [ST0350H1W-RSLW-F]
3.5" TFT LCD Module (320 x 240) Wide Viewing Type [ST0350H1W-RSLW-F]
Important Note: Currently,our direct shopping page is designed for orders from Japan. However,we welcome orders from customers outside of Japan. Please submit a direct inquiry using the form "Request Quotation / OtherInquiry" or send an email to s.shop@santekdisplay.com.
Controller Board and LCD Kit are also available for most of our Santek standard LCD Modules. Please contact us for inquiry.
SKU:ST0350H1W-RSLW-F
Couldn't load pickup availability
Spec Overview
| Size | 3.5" |
| Resolutions | 320 x 240 QVGA |
| Santek Model No. | ST0350H1W-RSLW-F |
| Module Size (W x H x T mm) |
76.90 x 63.90 x 2.93 |
| Active Area (W x H mm) |
70.08 x 52.56 |
| Interface | 3-wire SPI + RGB 24 bits |
| Brightness | 300 cd/㎡ |
| Operating Temperature | -20 ~ 70 °C |
| Viewing Angle | Wide (All Direction) |
Once you log in, you will return to top page. Select any products to download Spec Sheet. Some spec / data sheets are currently in preparation.
![3.5" TFT LCD Module (320 x 240) Wide Viewing Type [ST0350H1W-RSLW-F]](http://santekdisplay.com/cdn/shop/files/ST0350H1W-RSLW-F-1.png?v=1722476597&width=1445)
![3.5" TFT LCD Module (320 x 240) Wide Viewing Type [ST0350H1W-RSLW-F]](http://santekdisplay.com/cdn/shop/files/Spec_ST0350H1W-RSLW-F_RS01.jpg?v=1722558522&width=1445)
![3.5" TFT LCD Module (320 x 240) Wide Viewing Type [ST0350H1W-RSLW-F]](http://santekdisplay.com/cdn/shop/files/ST0350H1W-RSLW-F-3.png?v=1722476597&width=1445)
![3.5" TFT LCD Module (320 x 240) Wide Viewing Type [ST0350H1W-RSLW-F]](http://santekdisplay.com/cdn/shop/files/ST0350H1W-RSLW-F-2.png?v=1722476598&width=1445)
